Disc Brake Kit, Rear, e-Brake, 5-Lug (Dual Pattern - Chevy/Ford - 5x4-3/4, 5x4-1/2)

AC Industries Long Spline Axle Rear Disc Brake Kit with e-Brake.

AC Industries' set the highest standard of disc brake kit quality with their unique nodular iron caliper brackets. The superior strength nodular iron caliper brackets maintains proper caliper-to-rotor alignment and will not flex, bend or crack during normal service, like the typical stamped metal brackets found in lower quality kits. Nodular iron caliper brackets offer a much higher level of increased safety, durability and longevity!

Kit includes:
(2) Rotors with 5-lug dual pattern: 5" x 4-3/4" & 5" x 4-1/2" (Chevy & Ford)
(2) Calipers
(2) Nodular iron caliper mounting brackets
(4) Brake pads #D201
(2) e-Brake cables
(2) Seal kit
Mounting hardware
Installation Instructions

Note: Requires two 25" long metal brake lines part #113611764B

Stud Installation Note: These drums/rotors are drilled & tapped with a 14mm x 1.5mm threaded holes. If you chose to use a lug bolt, test fit the wheel to the rotor/drum before installation to confirm that the lug bolt doesn't protrude past the inside of the rotor/drum and hit other components. Check with the wheel manufacture or your installer to find out what stud is right for you.

Screw in Wheel Studs:
Wheel Stud, 14mm x 1/2", part #601102
Wheel Stud, 14mm x 12 mm, part #601115
Wheel Stud, 14mm x 14mm, 1 1/2" long, part #601111
Wheel Stud 14mm x 14mm, 1 3/4" long, part #601120
Wheel Stud, 14mm x 14mm, 2 1/2" long, part #601121

Application Info:
